Victor/RUOSHUI 05S 4-20ma Signal Generator Loop Calibrator mA Loop Calibrator,0.05%(RUOSHUI 05S)

YuqiaoTime VICTOR/RUOSHUI 05S 4-20ma Signal Generator Loop Calibrator mA Loop Calibrator,0.05%(RUOSHUI 05S)

• Measurement with basic accuracy of 0.02%, output with basic accuracy of 0.05%. 5 digits display for measured value. Measurements: DC current, DC voltage as well as providing 24V loop voltage and measuring current simultaneously. Analogue output: DC current and simulating transmitter.
• Providing loop voltage supply of 24V. Current displayed in Am and Am% format. The step, zero and full output provided with a fast operation. Output signal generates a auto ramp current output (4～20mA) at both fast and slow speeds. The step, zero and full output provided with a fast operation. Adjustable output gain. Built-in self-tests with closed-case calibration (no internal calibration adjustment).
• LCD: 61.8×29.4mm Operating requirements: Operating temperature: 0 to 50ºC. Operating humidity: ≤85%RH. Storage requirements:
• Storages temperature: -25 to 60ºC. Storage humidity: ≤90%RH (non-condensing). 4. certified as compliant to IEC1010 provisions(Safety standard issued by International Electro technical Commission) certified as compliant to IEC / ENEN61326-1 EMC standard Certified as compliant to IEC 60068-2-64:2008,IEC 60068-2-32:2008 with respect to vibration.
• 2×1.5AA-size alkaline batteries, automatic power-off. Seize and weight: 180×90×47mm, about 500g. Accessories: a pair of test leads. Options: TAS-U-5.
